WMD Voltera Metron Expander back in stock!
http://www.boutiquepedalnyc.us/wmd-voltera-metron-expander/
If you have Metron (trigger & gate sequencer), you know how powerful it can be in many ways~
Now you have a great partner to make your Metron even more powerful!!!
Voletra adds 4 bipolar voltage tracks in 4hp…
You can add up to 16 Volteras to do 64 CV Sequencing lanes with your single Metron!!!
With independent voltage ranges and quantize settings per track, Voltera allows for real time control over 4 different parameters at once, allowing you to dial that track to the parameter you are sequencing.
Sequence melodies, modulate parameters, and more with ease by adding Voltera to your METRON set up.
METRON must be updated to FIRMWARE V1.3
See METRON MANUAL for use instructions.
- 4 Bi-Polar Voltage outputs in 4HP
- Integrated user interface with METRON
- Quantized and Unquantized Voltages
- Stackable - up to 16 Voltera Modules to 1 METRON
- Independent voltage ranges per output
- Analog style programming
- Digital accuracy
- Fast tactile interface
- Stepped voltage recording
SPECS
Dimensions:
Width: 4HP (20.32mm)
Height: Eurorack 3U (128.5mm Panel, 112mm PCB behind panel)
Depth Including Cables: 43mm
Power:
16 pin Eurorack standard power cable
Reverse Polarity Protected
Do not connect power to expansion headers.
Typical Power Consumption: +12V: 60mA, -12V: 15mA
Outputs:
Channel Outputs 1-4: 470Ω Impedance, -5V to +5V
Channels are simultaneously updated.
Regulatory:
RoHS, CE, & WEEE Compliant
Made with Lead Free solder and processes
