4ms RCD Breakout

The RCD Breakout adds features to the Rotating Clock Divider module. Six switches allow you to set the maximum Divide-by amount, Gate or Trigger mode, Counting mode, Spread mode, and Auto-Reset. The RCD Breakout requires the RCD to function, and does not use any extra power.

Features

• Gate Counting: Down/Up
• Gate/Trigger mode
• Divide range up to Divide-by-64
• Spread mode: Spread mode causes the output to "spread" evenly amongst the entire max division range (see manual).
• Auto-reset: 16/off

Module size:
The RCD is 4HP and 48mm (1.85")

Power consumption:

• +12V rail: __mA
• +5V rail: not used
• -12V rail: not used
